Telemecanique now offers a new generation of expandable intelligent relays, offering substantial advantages in flexibility and functionality. Ladder programming is possible using the built-in LCD display and eight operation buttons. Subscribe to Automation-Talk by Email.Omron ZEN logic modules provide relays, timers, counters, and time switches all in one unit. Also you can subscribe to get all latest updates via e mail. Both the zen and pdf file are included and also you can test the program in the zen programming software simulator.Īlso keep reading here for latest plc programming tips and tricks. We have made a sample program, you can download it from below. So this technique can prove beneficial in the case when timers are falling short. So in this way these counters will behave as timer of 10 second, 15 second and 20 seconds. And in the input condition of all the counters put the Timer Done bit. Note :- Take the timer as flashing type i.e the timer will remain on and off simultaneously for the value set until the input condition is true.Īfter that make 3 counters and in the preset value put 10, 15 and 20 seconds. Then first of all make a timer with preset value as 1 second.
Suppose that we need a timer of 10 seconds, another timer of 15 seconds and third timer of 20 seconds. If it is required to use more than 16 timers and counters are free than we can make the plc logic in such a way that counter will work as timer. Make Counter to Work as Timer in Omron Zen PLC :.
Some times it happens that we need to use more than 16 timers in our program, so in that case what can be the possible solution? Only 16 timers & 16 counters are available in Zen Programmable Relay.
However Zen comes in different models and also analog Inputs can be connected.But the number of timers & Counter are limited. Zen is a programmable relay by Omron, it is a very basic PLC and generally used for small scale applications.
